Part Name | Material | Q’TY | |
Body | A105N | F316 | 1 |
Seat | PTFE | 2 | |
ball | 316 | 1 | |
cap | A105N | F316 | 1 |
Stem | 316 | 1 | |
Packing | Graphite | 1 | |
Handler | 304 | 1 | |
Stem nut | 304 | 2 | |
Anti static devise | SS | 2 | |
Stem sealing | PTFE | 1 | |
Gland | SS316 | 1 | |
Gasket | Graphite | 2 | |
尺寸表 |
NPS | Φd | G | L | H | W |
1/4 | 6 | 1/4"-18NPT | 60 | 55 | 120 |
3/8 | 10 | 3/8"-18NPT | 60 | 60 | 120 |
1/2 | 12.7 | 1/2"-14NPT | 75 | 65 | 150 |
3/4 | 17.5 | 3/4"-14NPT | 80 | 72 | 150 |
1 | 22 | 1"-11-1/2NPT | 90 | 80 | 170 |
1-1/4 | 28.5 | 1-1/4"-11-1/2NPT | 110 | 80 | 170 |
1-1/2 | 35 | 1-1/2"-11-1/2NPT | 120 | 105 | 240 |
2 | 47.5 | 2"-11-1/2NPT | 140 | 114 | 240 |
